Our Services
- High speed, high density PCB design.
- Mix technology analogue / digital PCB designs.
- Handling special nets.
- Ground shielding on special nets.
- Design for manufacturing.
- Selecting correct style of copper pouring on power & ground nets to avoid bridging when soldered on wave soldering machines.
- Making CNC programming for PCB manufacturing.
Complexity Expertise
Board size : | Few square inches to 100+ square inches |
|---|---|
Layers (no.s) : | Single Sided, Double Sided, 4 layers |
No. of nets (nos) : | 10000+ on a single controlled impedance board |
Density (pins/sq inch) : | 120 + |
No. of components on a single board : | 1500 + |
Voltages on a single board : | 1 – 8 (like +12V, 3.3V, 2.5V, 1.5V etc.) |
Trace widths on single board : | 4 mil – 40 mil |
Range of target applications : | Consumer electronics board to Industrial boards |
Range of components : | Simple logic devices to multi-million gates IC’S |
Verification
- Air gap
- Mechanical fit
- Hanging traces
- Cross Probing of Schematic and PCB’s
- DRC (Design Rule Checking)
- Silk-screen overlap
- Gerber using Excel CAM
Deliverables
- Schematic, Final Net-list
- PCB layout files
- Gerber Files for all layers in Extended Gerber format with embedded apertures
- N.C. Drill file in TAP format
- Drill Drawing (Fab Drawing)
- Layer stack report
- Films of all layer (optional)
- CNC drilling & routing programming file with report (optional)
